TS 600 EVO MULTI4

Engine Driven Welder Diesel DEUTZ F4L2011 - Three-phase asynchronous Alternator - Air/Oil cooling

WELDING

Welding current: 20A ÷ 550A (50Hz)
Welding current: 20A ÷ 600A (60Hz)
Service: 500A - 60% / 400A - 100% (50Hz)
Service: 550A - 60% / 450A - 100% 600A (60Hz)
Open circuit voltage (no-load voltage): 72 Vcc (77.5 Vcc dc peak) (50Hz)
Open circuit voltage (no-load voltage): 75 Vcc (80 Vcc dc peak) (60Hz)

POWER RATINGS

Three-phase power: 18 kVA / 400 V / 26 A (50Hz)
Three-phase power: 20 kVA / 400 V / 28.9 A (60Hz)
Single-phase power: 10 kVA / 230 V / 43.5 A (50-60Hz)
Single-phase power: 5 kVA / 115 V / 43.5 A (50-60Hz)

GENERAL SPECIFICATION

Tank capacity: 60 l (50-60Hz)
Running time (welder 60%): 12.7 h (50Hz)
Running time (welder 60%): 10.5 h (60Hz)
Measured acoustic power LwA (pressure LpA): 95 dB(A) (70 dB(A) @ 7 m) (50Hz)
Guaranteed acoustic power LwA (pressure LpA): 96 dB(A) (71 dB(A) @ 7 m) (50Hz)
Acoustic power LwA (pressure LpA): 98 dB(A) (73 dB(A) @ 7 m) (60Hz)
Weight: 870 Kg (50-60Hz)
Dimensions max. on base Lxlxh: 1600x790x1125 mm (50-60Hz)

More Information

Engine

Model	Fuel	Starter	Output	Cylinders / Displacement	Speed	Cooled
DEUTZ F4L2011	Diesel	Electric	27.7 kW (37.7 hp) (50Hz)	4/ 3100 cm³	1500 rpm	Air
DEUTZ F4L2011	Diesel	Electric	32.8kW (44.6 hp) (60Hz)	4/ 3100 cm³	1500 rpm	Air

ENGINE PROTECTION LOVATO

The Lovato RGK420SA control unit has an ignition key and push buttons for controlling the engine. A wide LCD display allows the visualization of alarms and the monitoring of machine parameters. The main features are:

User interface with symbols, codes and texts.
Setpoints adjustable via controller buttons or PC
Remote Start and Stop
Configurable inputs and outputs
NFC interface for wireless programming

DOWNLOAD MANUAL

MULTI4 CONTROL

MULTI4 CONTROL

EVO MULTI4 is the new panel for engine driven welders by MOSA, created with the purpouse of giving to the user a complete new experience in which it is possible to control each parameter of the welding:
